Product Details:
Payment & Shipping Terms:
|
| Application: | Oilfield Shale Shaker | Warranty: | 12 Months |
|---|---|---|---|
| Package: | Wooden Case | Advantage: | High Performance |
| Main Parts: | Shaker Screens, Vibrating Motors, Rubber Springs, Stainless Steel Bolts, Screen Repair Plug, Wedge Block | Applicable Shaker: | BEM, Linear Shale Shaker |
| MOQ: | 1 Pc | Material: | Carbon Steel |
| High Light: | API Replacement Shale Shaker Parts,Solid Control Shale Shaker Parts,Carbon Steel Shale Shaker Parts |
||
API Standard Shale Shaker Spare Parts for Solid Control
Product Overview
Xi'an TianRui Petroleum Machinery Equipment Company Limited is a professional manufacturer of various oilfield equipments and solid control equipment since 2010, restructured enterprise of SINOPEC. Our group have 10 years export experience and 9 subsidiary factories, more than 500 employees. We are the first-class supplier of resources market of SINOPEC and CNPC.
We provide shale shaker parts for our clients. Shale shaker parts mainly contains : shaker screens, vibrating motors, rubber springs, stainless steel bolts, screen repair plug, wedge block and so on.
Main Features of Our Drilling Shale Shaker
Technical Sheet of Drilling Shale Shaker
| Model | TRPS703 | TRPS585-4 | TRZS703 | TRZS585 |
| Vibration Motion | Balanced Elliptical Motion | Linear Motion | ||
| Treatment Capacity | 130m³/h | 140m³/h | 120m³/h | 130m³/h |
| Motor Power | 1.94+1.0kw | 1.94+1.0kw | 1.5KW×2 | 1.72KW×2 |
| Screen Specs. | (700×1250mm)×3 | (585×1165mm)×4 | (700×1250mm)×3 | (585×1165mm)×4 |
| Screen Area | 2.6m² | 2.7m² | 2.6m² | 2.7m² |
| Vibration Strength | ≤7.1G | ≤7.1G | ≤7.1G | ≤7.1G |
| Double Amplitude | 7mm | 7mm | 6mm | 6mm |
| Deck Adjustment | -1°～+5° | -1°～+5° | -1°～+5° | -1°～+5° |
| Ex Standard | ExdIIBt4 / IECEX / A-TEX | |||
| Weight | 1630kg | 1618kg | 1620kg | 1600kg |
| Dimension | 2770×1785×1690mm | 2966×1600×1280mm | 2770×1785×1690mm | 2966×1600×1280mm |
| Remark | Above data are tested from the drilling mud with viscosity 45s,and specific gravity 1.2g/cm3. | |||
Xi'an TianRui Petroleum Machinery Equipment Company Limited is an ISO-9001, ISO-14001, OHSAS-18001 certified company and has all the quality systems in place for design, planning, manufacturing and quality monitoring & traceability to ensure that our products match the highest quality & reliability Standards similar to any International major in this field.
Taking quality as the life of company, be targeted at "sincere cooperation, win-win", we would like to be the connection between the world and China, and supply the best "one-stop" service for the customer from all over the world. We sincerely hope to cooperate with all friends both in China and abroad to create brilliant achievements in the future.
FAQ:
1)Why choose us?
We can provide you best quality with reasonable price.
2)How can I know the material is correct and acceptable?
Material certificate (inspection certificate) is available on Request.
3)I cannot find the products I want on your site. Are you able to help me to locate it?
Yes, we will try our best to give you the product you want.
4) What products you are specialized in?
We are specialized in all kinds of tubing protectors.
Contact Person: sunny
Tel: +8613186019379
