| Key Words: | Mission Centrifugal Pump For Hot Sale | Flow Rate: | 90m3/h |
|---|---|---|---|
| Lift: | 30m | Impeller Diameter: | 10inch |
| Power: | 22kw | Electric System: | 60HZ |
| Ex Standard: | ExdIIBt4/IECEX/A-TEX | Weight: | 583kg |
| Dimension: | 1648*568*800mm | Color: | Green Paint |
| Highlight: | industrial centrifugal pumps,horizontal centrifugal pump |
||
High Quality Bearing for Horizontal Mission Sand Pump with Short Delivery & Good Price
Product Introduction
Centrifugal pump is important equipment used in solids control system. It provides drilling fluid to other equipment by its suction and pumping out function. This could achieve transferring of drilling fluids. Its main working principle is the centrifuging power coming from rotating impeller.
Centrifugal pump is used to transport fluid by conversion of rotational kinetic energy to the hydraulic energy of the fluids flow. The rotational energy typically comes from an engine or electric motor. We supply pumps driven by 10HP to 100HP, which are popular in drilling mud process. Pumps size ranges 3x2, 4x3, 5x4, 6x5, 8x6. They will perform differently under different power, voltage, or frequency.
Advantages of TRSB Series Centrifugal Pump:
Specification of TRSB Series Drilling Centrifugal Pump
| Model | Power | Flow | Lift(m) | Efficiency | NPSH | Electric |
| TRSB8×6-14J | 75KW | 320m3/h | 40m | 65% | 5 | 50HZ |
| TRSB8×6-12J | 355m3/h | 43m | 66% | 4.8 | 60HZ | |
| TRSB8×6-13J | 55KW | 290m3/h | 33m | 64% | 5.5 | 50HZ |
| TRSB6×5-12J | 196m3/h | 48m | 61% | 3 | 60HZ | |
| TRSB6×5-13J | 45KW | 180m3/h | 34m | 60% | 3 | 50HZ |
| TRSB5×4-14J | 149m3/h | 61m | 58% | 4.6 | 60HZ | |
| TRSB6×5-12J | 37KW | 160m3/h | 30m | 60% | 3 | 50HZ |
| TRSB5×4-12J | 112m3/h | 45m | 58% | 4.6 | 60HZ | |
| TRSB6×5-11J | 30KW | 120m3/h | 21m | 62% | 2.5 | 50HZ |
| TRSB5×4-12J | 112m3/h | 37m | 57% | 4.6 | 60HZ | |
| TRSB5×4-12J | 22KW | 90m3/h | 30m | 56% | 4.5 | 50HZ |
| TRSB5×4-10J | 105m3/h | 30m | 57% | 4.2 | 60HZ | |
| TRSB5x4-11J | 18.5KW | 90m3/h | 24m | 56% | 4.5 | 50HZ |
| TRSB4x3-12J | 55m3/h | 46m | 48% | 4 | 60HZ | |
| TRSB4x3-13J | 15KW | 50m3/h | 40m | 48% | 4.5 | 50HZ |
| TRSB4x3-11J | 54m3/h | 35m | 47% | 4 | 60HZ | |
| TRSB4x3-12J | 11KW | 45m3/h | 30m | 47% | 4 | 50HZ |
| TRSB3x2-12J | 28m3/h | 45m | 40% | 3.1 | 60HZ | |
| TRSB3x2-12J | 7.5KW | 45m3/h | 24m | 46% | 4 | 50HZ |
| TRSB3x2-11J | 25m3/h | 35m | 41% | 3.1 | 60HZ | |
| TRSB3x2-11J | 5.5KW | 20m3/h | 23m | 39% | 3 | 50HZ |
TR Solids Control is an innovative manufacturer of Mission centrifugal pump in China. Our sand pump can be used in city bored piling construction, trenchless HDD & tunnelling, oil & gas drilling, oil sludge treatment etc. Welcome to consult us now!
Competitive Advantages
1. We offer high quality products at competitive price.
2. Shortest delivery time.
3. Flexible payment terms.
4. Timely after-sale service.
5. Most of our equipment can be replaceable with international brands.
6. Our products have been exported to Argentina, Egypt, US, Australia, Romania, Pakistan, Dubai, Abu Dhabi, Iran, India, Indonesia, Vietnam, Malaysia and many other countries.
