SS304 Low Noise Centrifugal Mud Pump 320m3/h Flow Rate For Drilling Fluid

SS304 Low Noise Centrifugal Mud Pump 320m3/h Flow Rate For Drilling Fluid
SS304 Low Noise Centrifugal Mud Pump 320m3/h Flow Rate For Drilling Fluid
video play

Large Image :  SS304 Low Noise Centrifugal Mud Pump 320m3/h Flow Rate For Drilling Fluid

Product Details:
Place of Origin: Xi'an,China
Brand Name: TR Solids Control
Certification: API Certificate, ISO Certified
Model Number: TRSB8*6-12J
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Wooden case or pallet
Delivery Time: 15 days after receiving deposit
Payment Terms: T/T, L/C, D/A, D/P, Western Union
Supply Ability: 50000 Sets / Month
Detailed Product Description
Key Words: Low Noise, No Pollution,Smooth Operation Centrifugal Pump For Hot Sale, With High Performance And Top Quality Flow Rate: 320m3/h
Lift: 40m Impeller Diameter: 12inch
Power: 75kw Electric System: 60HZ
Ex Standard: ExdIIBt4/IECEX/A-TEX Weight: 1096kg
Dimension: 1968*650*1017mm Color: Green
High Light:

Low Noise Centrifugal Mud Pump

,

SS304 Centrifugal Mud Pump

,

320m3/H Centrifugal Slurry Pump

High Quality Solid Control System Oilfield Centrifugal Pump for Drilling Fluid



Introduction


Centrifugal Pump is also called as Sand Pump, Mixing Pump, Feeding Pump, Replenishing Pump and Filling Pump. It is the ideal matching equipment to provide impetus for desander, desilter and Jet mud mixer. Centrifugal pump can also be an assistant mud infusion pump and trip pump at well head. TR centrifugal pump can realize the quick positioning and installation.



Compared with the general pump, our TRSB series pump is with excellent performance, high traffic, high temperature, long service life, easy maintenance, high reliability and remarkable energy saving characteristics. Now it is widely used around the world on onshore and offshore drilling site. We will provide customers with the best pumps to meet different requirements.



Why Choose TR Centrifugal Sand Pump:

  1. Adopt national famous brand explosion-proof motor.
  2. Painting: Heavy anti-corrosion paint adopt national famous Dewei Brand.
  3. Sand Pump body and impeller use cast steel material, optimize structure, small size
  4. Adopt SS304 material to achieve a good seal effect, environmental protection.
  5. Low noise, no pollution, smooth operation.
  6. Spraying Processing: grinding and sandblasting;with base coating, middle coating and finish coating.

Parameters of Centrifugal Sand Pump



Model Power Flow Lift(m) Efficiency NPSH Electric
TRSB8×6-14J 75KW 320m3/h 40m 65% 5 50HZ
TRSB8×6-12J 355m3/h 43m 66% 4.8 60HZ
TRSB8×6-13J 55KW 290m3/h 33m 64% 5.5 50HZ
TRSB6×5-12J 196m3/h 48m 61% 3 60HZ
TRSB6×5-13J 45KW 180m3/h 34m 60% 3 50HZ
TRSB5×4-14J 149m3/h 61m 58% 4.6 60HZ
TRSB6×5-12J 37KW 160m3/h 30m 60% 3 50HZ
TRSB5×4-12J 112m3/h 45m 58% 4.6 60HZ
TRSB6×5-11J 30KW 120m3/h 21m 62% 2.5 50HZ
TRSB5×4-12J 112m3/h 37m 57% 4.6 60HZ
TRSB5×4-12J 22KW 90m3/h 30m 56% 4.5 50HZ
TRSB5×4-10J 105m3/h 30m 57% 4.2 60HZ
TRSB5x4-11J 18.5KW 90m3/h 24m 56% 4.5 50HZ
TRSB4x3-12J 55m3/h 46m 48% 4 60HZ
TRSB4x3-13J 15KW 50m3/h 40m 48% 4.5 50HZ
TRSB4x3-11J 54m3/h 35m 47% 4 60HZ
TRSB4x3-12J 11KW 45m3/h 30m 47% 4 50HZ
TRSB3x2-12J 28m3/h 45m 40% 3.1 60HZ
TRSB3x2-12J 7.5KW 45m3/h 24m 46% 4 50HZ
TRSB3x2-11J 25m3/h 35m 41% 3.1 60HZ
TRSB3x2-11J 5.5KW 20m3/h 23m 39% 3 50HZ



SS304 Low Noise Centrifugal Mud Pump 320m3/h Flow Rate For Drilling Fluid 0



TR Solids Control is absorbed in developing our product line continuously and offering innovative solutions to our customers. Our centrifugal pump can be totally interchangeable with Mission series pump. Our centrifugal pumps have been exported to Russia, America, Middle East, South America, Southeast Asia, Central Asia, African, Australia, Europe etc. Our company is willing to cooperate and make common progress with friends at home and abroad with first-class products, first-class service and reasonable prices.



Competitive Advantages


1. We offer high quality products at competitive price.
2. Shortest delivery time.
3. Flexible payment terms.
4. Timely after-sale service.
5. Most of our equipment can be replaceable with international brands.
6. Our products have been exported to Argentina, Egypt, US, Australia, Romania, Pakistan, Dubai, Abu Dhabi, Iran, India, Indonesia, Vietnam, Malaysia and many other countries.



Company Tenet
Customer's satisfaction is the highest pursuit of TR Solids Control.
