Fine Grinding Processing Mud Mixer Machine Antiseptic 18.5kw

China Xi'an TianRui Petroleum Machinery Equipment Co., Ltd. certification
China Xi'an TianRui Petroleum Machinery Equipment Co., Ltd. certification
Professional solids control manufacturer. Their Product replacement shaker screens have long service time and good treatment. They help us a lot!

—— Mr. Samir

I purchased 10 pcs TRSB8*6-12J centrifugal pump from TR Solids Control. They are good-looking and really have good quality and considerate after sales service!

—— Mr. Warren

We ordered a set of mud system for our oilfield drilling field, TR product showed good performance in the site. We like that very much!

—— Diego Olbrich

TR shaker screens have top quality and good price. We have been purchasing them from TR for more than 4 years.

—— Nghiem Thic Hai

Good company with nice service and high quality and high reputation. One of our reliable supplier , goods are delivered in time and nice package.

—— Hossein Jafari

Thanks for your good after-sale service. Excellent training and technology support helps me a lot.

—— Ms. Crina

We start use TRZS703 Shale Shaker since 2012, now we have 8 sets working in our customer's oilfield site, perfect machine with reasonable price.

—— S. A. Kazi

I'm Online Chat Now

Fine Grinding Processing Mud Mixer Machine Antiseptic 18.5kw

Fine Grinding Processing Mud Mixer Machine Antiseptic 18.5kw
Fine Grinding Processing Mud Mixer Machine Antiseptic 18.5kw
video play

Large Image :  Fine Grinding Processing Mud Mixer Machine Antiseptic 18.5kw

Product Details:
Place of Origin: Xi'an,China
Brand Name: TR Solids Control
Certification: API Certificate, ISO Certificate
Model Number: TRJBQ18.5
Payment & Shipping Terms:
Minimum Order Quantity: 1 Pc
Price: Negotiable
Packaging Details: Wooden or iron pallet
Delivery Time: 10 days after receiving deposit
Payment Terms: T/T, L/C, D/A, D/P, Western Union
Supply Ability: 2000 Sets / Month
Detailed Product Description
Motor Power: 18.5kw Impeller Speed: 60/72r/min
Impeller Diameter: 1000mm Impeller Qty: 2pcs
Ex Standard: ExdIIBt4/IECEX/A-TEX Dimension: 1510*890*753mm
Weight: 740kg Key Words: High Quality Mud Agitator For Well Drilling Fluid Mixing System, With Excellent Performance And Long Service Time
High Light:

Antiseptic Mud Mixer Machine

,

Fine Grinding Processing Drilling Mud Agitator

,

18.5kw Mud Mixer Machine

API Solids Control Oilfield Drilling Mud Agitator / Good Quality Mud Agitator

Product Introduction



Drilling mud agitator is a kind of solids control equipment combined of reducer and explosion-proof motor. It’s easy to maintain, and suitable for use in the field of harsh conditions. Mud agitator has a large agitation strength, wide spread, and can reduce starting torque.



TRJBQ series mud Agitator, Less than 3 kW drilling mud Agitator adopts the blender cycloid speed reducer, and it is applied to the drug liquids mixing tank. This mud agitator has the advantage of compact structure, so it occupies small area. More than 7.5 kW Mud Agitator uses the turbo and worm gear speed reducer, with the large torque transmission, the revolution is steady, it works reliablely and has great merit. Common model of mud agitator is JBQ5.5kW, JBQ7.5kW, JBQ11kW and JBQ15kW.


Advantages of Our mud agitator:

  1. Small size, compact structure.
  2. The gearbox adopt more reliable worm gear.
  3. Good heat exchange performance makes agitator faster cool down.​
  4. Long  lifespan, less wearing parts, and cost-effective.
  5. Motor and gear box will be connected by coupling directly. Agitation speed is more stable.
  6. Using high-pressure airless spraying equipment construction, after primer, intermediate coat, finishing coat and other processes to achieve beautiful appearance and antiseptic effect.

Parameters of Our Drilling Mud Agitator


Model Motor Power Impeller Speed Impeller Diameter Impeller Qty. Explosion-proof Standard Weight Dimension
TRJBQ3 3kw 60/72r/min 600mm 1



ExdIIBt4/IECEX/A-TEX

190kg 909×525×527mm
TRJBQ5.5 5.5kw 600mm 1 250kg 1072×610×588mm
TRJBQ7.5 7.5kw 650mm 2 380kg 1157×670×607mm
TRJBQ11 11kw 800mm 2 430kg 1297×740×692mm
TRJBQ15 15kw 950mm 2 480kg 1330×890×747mm
TRJBQ18.5 18.5kw 1000mm 2 740kg 1510×890×753mm
TRJBQ22 22kw 1100mm 2 780kg 1529×890×753mm
Remark Above weight and dimension exclude mud agitator shaft.



Fine Grinding Processing Mud Mixer Machine Antiseptic 18.5kw 0



TR Solids Control as a professional manufacturer for soilds control equipments, we have designed lots of high-quality products, and JBQ series Agitator is one of them. To keep both the mud uniformity and the suspension of solids, the mud agitator is used to agitate the mud consecutively and reliably.This agitator agitates the mud to make cuttings, silt and sand pass the solids control system without being precipitated onto the tank bottom. Therefore, it is a reliable product in the solids control system.



Competitive Advantages
1. We offer high quality products at competitive price.
2. Shortest delivery time.
3. Flexible payment terms.
4. Timely after-sale service.
5. Most of our equipment can be replaceable with international brands.
6. Our products have been exported to Argentina, Egypt, US, Australia, Romania, Pakistan, Dubai, Abu Dhabi, Iran, India, Indonesia, Vietnam, Malaysia and many other countries.


Company Tenet
Customer's satisfaction is the highest pursuit of TR Solids Control.
