60FT 5000PSI WP Oilfield Drilling Rotary Hose For Energy Mining

60FT 5000PSI WP Oilfield Drilling Rotary Hose For Energy Mining
60FT 5000PSI WP Oilfield Drilling Rotary Hose For Energy Mining 60FT 5000PSI WP Oilfield Drilling Rotary Hose For Energy Mining 60FT 5000PSI WP Oilfield Drilling Rotary Hose For Energy Mining

Large Image :  60FT 5000PSI WP Oilfield Drilling Rotary Hose For Energy Mining

Product Details:

Place of Origin: Xi'an China
Brand Name: TR Solids Control
Certification: API Spec 7K, ISO
Model Number: Customized

Payment & Shipping Terms:

Minimum Order Quantity: 1 pc
Price: Negotiable
Packaging Details: Pallet or wooden case
Delivery Time: 15 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union
Supply Ability: 60000 M Per Month
Detailed Product Description
Size: 4in-12inch Grade: A, B, C, D, E, F, G
Connection: Hammer Uion Connector Code: TBG, LP
Material: BR Rubber Usgae: Energy & Mining
Safety Chain: Included Pressure: 1500-15000 PSI
High Light:

Oilfield Drilling Rotary Hose

,

60FT Drilling Rotary Hose

,

BR Rubber Drilling Rotary Hose

Oilfield Drilling Rotary Hose with 60 FT. 5000 PSI WP



Construction



It is composed of an inner rubber protection layer, middle rubber layer, steel wire spiral layer and external rubber cover.



Applications: Steel wire spiral drilling rubber hoses are used in oil fields, well cementing, well repairing, geological explorations, small drilling machine, and water conveyance at coal excavations. They are useful to carry slurry, water at environmental temperature, and other fluids.

Working Temperature: From -40oC up to +100oC
Executive Standard: GB10544-2003, API Spec 7K, SY 5469.



Product Construction



  • Inner rubber protection layer
  • Middle rubber layer
  • Steel wire spiral layer
  • External rubber cover
  • Built-in API couplings with male thread, integral unions and couplings, single couplings, flanges



Service Objective

  1. Adhere to the best quality,pursue the excellent sevices
  2. Continuously research and develop high-quality products which are new and practical and can meet the market demand;
  3. Make every effort to provide users with satisfactory pre-sale,in-sale and after-sales services,it is the etemal theme of our company to seek development,and hereon our company promises to the vast numbers of users.

Main Technical Parameters of Drilling Rotary Hose



Size ID OD Working Pressrue Burst Pressure Bend Radius Weight
TYPE mm mm BAR psi BAR psi mm Kg/m
2" 51 69 35 5072 87.5 12679 900 5.7
2.5" 64 84 35 5072 87.5 12679 1100 6.7
3" 76 107 35 5072 87.5 12679 1200 16.2
3.5" 89 120 35 5072 87.5 12679 1300 18.4
4" 102 133 35 5072 87.5 12679 1400 20.3
2" 51 72 70 10143 175 25358 1000 6.2
2.5" 64 88 70 10143 175 25358 1200 7.4
3" 76 116 70 10143 175 25358 1300 23.7
3.5" 89 129 70 10143 175 25358 1400 26.6
4" 102 142 70 10143 175 25358 1600 29.8



60FT 5000PSI WP Oilfield Drilling Rotary Hose For Energy Mining 0
