| Size: | 5/8"to 1-1/8" | Material: | Iron, Alloy |
|---|---|---|---|
| Grade: | C, D, K, KD, H | Color: | Black, Blue |
| Using Medium: | Crude Oil | Power Source: | Mechanical |
| High Light: | Polished Sucker Pony Rod,Drilling Polished Pony Rod,API Mechanical Sucker Pony Rod |
||
Oil Rig Drilling Polished Sucker Rod and Pony Rod
Product Overview
Our sucker rod conforms to API Specification 11 B (Oil extraction Rod Standard) and other related standard. Authorized to use the API monogram, our company can produce conventional type polish rod, electroplate polish rod and spray welding polish rod with any specification.
Hollow sucker rod has hole in the middle and has the characters: chemicals and hot oil can be injected through the inner hole to decrease the viscosity of the oil and the paraffin deposit in the well thus the pump efficiency is increased; The smaller passage and the faster flow velocity can avoid the sand deposit efficiently while use hollow sucker rod in the sand well; Matched with the rodless pump hollow sucker rod can substitute the tubing; Hollow sucker rod can be used to drive the PC pumps as it can bear larger torque.
Products and services are available as follows:
1. Grade C, D, K, KD, HL sucker rods and pony rods, drive rods, anti-side-abrasion sucker rods, pump rods, sinker bars, solid polished rods, special polished rods and inserted joint rods;
2. Grade T, KD and SM rod coupling in full size and slim hole diameters, adaptor couplings, anti-side-abrasion couplings, polish rod couplings and ultra-high strength couplings.
3. Sucker rod centralizer, polish rod clamp.
4. Sucker rod refurbishing.
Technical Parameters of Our Oilfield Sucker Rod
| Nominal Size | 1-1/8 (in) | 1-1/4 (in) | 1-1/2 (in) | ||||
| in. | mm | in. | mm | in. | mm | ||
| Outside Diameter | Dimension | 1.125 | 28.58 | 1.25 | 31.75 | 1.50 | 38.10 |
| Tolerances | +0.005 -0.010 |
+0.13 -0.25 |
+0.005 -0.010 |
+0.13 -0.25 |
+0.005 -0.010 |
+0.13 -0.25 |
|
| Nominal Diameterof Pin-thread | Dimension for referance | 0.938 | 23.83 | 1.188 | 30.18 | 1.375 | 34.93 |
| 1.063 | 27.00 | ||||||
| Note:sizes of sucker rods with which used | Nominal Dimension (for referance) | 5/8 | 7/8 | 1 | |||
| 3/4 | |||||||
| Note:Standard lengths | Dimension |
ft 22, 26,30,36, 40 |
m 4.9, 6.7,7.9, 9.1, 11.0,12.2 |
ft 22, 26,30,36, 40 |
m 4.9, 6.7,7.9, 9.1, 11.0,12.2 |
ft 22, 26,30,36, 40 |
m 4.9, 6.7,7.9, 9.1, 11.0,12.2 |
Xi'An TianRui Petroleum Machinery Equipment Company Limited is an international comprehensive industrial group committed to making the extraction of oil and gas more efficient, providing customers one-stop solutions including R&D of high-end oil and gas equipment, oil and gas energy engineering and oil field integration services, industry + internet platform services, industry training and human resource services. Taking the full advantages of equipment, technology, services, talents and platforms, and multi-field business models development, we are upgrading from solutions providing to a win-win eco-industrial chain.
We have a rich history, spanning more than 10 years in the mining and drilling industry. This long record of experience has led us to become the China leader and expert we are today. With one manufacturing location, some of the most advanced drilling technology on the market, we continue to be innovators of the industry. Until now our products are popular in United States , Australia, England, France, Japan, Brazil, India, Russia and many other countries & regions.
Competitive Advantages
1. We offer high quality products at competitive price.
2. Shortest delivery time.
3. Flexible payment terms.
4. Timely after-sale service.
5. Most of our equipment can be replaceable with international brands.
6. Our products have been exported to Argentina, Egypt, US, Australia, Romania, Pakistan, Dubai, Abu Dhabi, Iran, India, Indonesia, Vietnam, Malaysia and many other countries.
