Drilling Mud Gas Separation 320m3/H Poor Boy Degasser

Drilling Mud Gas Separation 320m3/H Poor Boy Degasser
Drilling Mud Gas Separation 320m3/H Poor Boy Degasser
video play

Large Image :  Drilling Mud Gas Separation 320m3/H Poor Boy Degasser

Product Details:
Place of Origin: Xi'an,China
Brand Name: TR Solids Control
Certification: API Certificate, ISO Certificate
Model Number: TRZYQ1200
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Pallet or wooden case
Delivery Time: 20 days after receiving deposit
Payment Terms: T/T, L/C, D/A, D/P, Western Union
Supply Ability: 500 Sets/Month
Detailed Product Description
Capacity: 320 M3/h Main Body Diameter: 1200mm
Inlet Pipe: DN125mm Output Pipe: DN250mm
Gas Discharge Pipe: DN200mm Weight: 2600 Kg
Dimension: 2200*2200*6634 Mm Application: Energy & Mining
High Light:

320m3/H Poor Boy Degasser

,

Drilling Mud Gas Separator

,

1200mm Poor Boy Degasser

320 m3/h Poor Boy Degasser / Mud Gas Separator for Drilling


Product Overview



ZYQ series Mud gas separator(Poor Boy Degasser) is professional equipment to treat the gas invade mud. When the drilling mud result gas invade, the proportion of its weight and viscosity have a greater deviation not to meet the requirements of drilling. The serious situation is that would cause Chung well, and even blowout accident occurred, if not to treat it timely. ZYQ series Mud gas Separator combined with the Electric Ignition Device can be used to ensure the drilling process smooth. It is divided into the normal pressure Mud gas separator and pressure auto-control Mud gas separator, according to the pressure. Mud gas Separator is your best choice to prevent drilling mud invasion.



TR Solids Control is a leader in mud gas separator. Our TRZYQ series mud gas separator is devided into normal pressure Mud gas separator and pressure auto-control Mud gas separator, according to the pressure. TR mud gas separator is a field proven and extremely reliable safety equipment designed for today’s challenging drilling operations. It is your best choice to prevent drilling mud invasion.



Design Advantages of TRZYQ Mud Gas Separator

  1. Skid-Mounted.
  2. Adopting bottom-sealing structure.
  3. Anti-corrosion epoxy coating to ensure long service life.
  4. Separated free gas from drilling fluids, including toxic gases such as hydrogen sulfide.
  5. Mainly used to clear away big bubbles of Φ3-Φ25mm.
  6. Reducing hazardous gas threat: separated free gas is discharged by vent lines to a safe place for combustion.
  7. Simple structure,large disposal capacity,high degassing efficiency,convenient transportation/installation.

Main Specification of TRZYQ Mud Gas Separator


Model TRZYQ800 TRZYQ1000 TRZYQ1200
Capacity 180 m³/h 240 m³/h 320 m³/h
Main Body Diameter 800mm 1000mm 1200mm
Inlet Pipe DN100mm DN125mm DN125mm
Output Pipe DN150mm DN200mm DN250mm
Gas Discharge Pipe DN200mm DN200mm DN200mm
Weight 1750kg 2235kg 2600kg
Dimension 1900*1900*5700mm 2000*2000*5860mm 2200*2200*6634mm


Drilling Mud Gas Separation 320m3/H Poor Boy Degasser 0



Why choose us TR Solids Control?


1. Own factories in China mainland.
2. Engaged in the solid control equipment for over 10 years.
3. Achieve patents for intellectual property protection.
4. QUALITY SESTEM to make sure the superior high quality.
5. Large product series for one-stop service.
6. Consulting, suggesting, help find perfect solution.



Our Mud Gas Separator is mainly used to remove the enormous free gas from drilling fluids, including poisonous gases like H2S. Currently it is widely used in Drilling Waste Management, city bored piling, trenchless HDD, oil & gas drilling, Coal Bed Gas Solids Control System, Oil Sludge Dewatering Systems, mining, Water Drilling, environment protection, Oil Mud Seperation etc.


Competitive Advantages


1. We offer high quality products at competitive price.
2. Shortest delivery time.
3. Flexible payment terms.
4. Timely after-sale service.
5. Most of our equipment can be replaceable with international brands.
6. Our products have been exported to Argentina, Egypt, US, Australia, Romania, Pakistan, Dubai, Abu Dhabi, Iran, India, Indonesia, Vietnam, Malaysia and many other countries.
