Product Details:
Payment & Shipping Terms:
|
| Nominal Bore: | 1 13/16"~7 1/16" | Operated Pressure: | 2000psi-15000psi |
|---|---|---|---|
| Performance Level: | PR1, PR2 | Specification Level: | PSL1-4 |
| Medium: | Mud, Natural Gas, Crude Oil | Usage: | Oil Extraction |
| High Light: | SSV Surface Safety Valve,API 6A Surface Safety Valve,PSL1-4 SSV Valve |
||
API 6A Hydraulic Surface Safety Valve / SSV for Oil and Gas
Product Overview
Surface safety valve (SSV) is a hydraulically actuated failsafe gate valve for producing or testing oil and gas wells with high flow rates, high pressures, or the presence of H2S. The SSV is used to quickly shut down the well upstream in the event of overpressure, failure, a leak in downstream equipment, or any other well emergency requiring an immediate shut down.
SSV is remotely operated by an emergency shutdown device (ESD), which can be triggered automatically by high or low pressure pilot actuators. If an emergency occurs, this feature reduces the possibility of personnel injuries.
Main Characterstics of TR Surface Safety Valve
Technical Specifications of Wellhead Surface Safety Valve
| Material Class | AA,BB,CC,DD,EE,FF,HH. 0.5, NL. |
|---|---|
| Valve Class | PSL1~PSL3G. |
| Valve Size | 1 13/16"~7 1/16". |
| Valve Pressure | 2000PSI~20000PSI. |
| Temp Range | K,L,N,P,S,T,U,V,X,Y. |
| Connecting Format | Flange |
| Working Temperature | High Temperature |
| Applicable Medium | Oil, Other |
| Type | Right-angle Type |
| Flow Direction | Bi-directional |
| Application | Adjust |
| Driving Mode | Hydraulic Control |
| Sealing Form | Flexible Seal |
| Material | Stainless Steel |
| Body Structure | Unclosed |
| Mpa | High Pressure |
RFQ
1.How do you transport the goods?
We transport the goods by container. we possesses long term cooperation with ship agency which can provide you lowest shipping fee. For samples we can send by express.
2.Can you satisfy my special requirement?
Definitely! we have strong design capacity and R&D capacity!
3.Which shipment terms can you accept?
EXW FOB CNF CIF DDU DDP
Our company is committed to develop, manufacture and supply a variety of oilfield equipments. Main products include: Petroleum equipment & tools such as drilling equipments, oil production equipments, oil pipes, wellhead equipments, download tools, well control equipments, cementing tools, and petrochemicals etc.
Competitive Advantages
1. We offer high quality products at competitive price.
2. Shortest delivery time.
3. Flexible payment terms.
4. Timely after-sale service.
5. Most of our equipment can be replaceable with international brands.
6. Our products have been exported to Argentina, Egypt, US, Australia, Romania, Pakistan, Dubai, Abu Dhabi, Iran, India, Indonesia, Vietnam, Malaysia and many other countries.
