1200mm Skid Mounted Oilfield Poor Boy Gas Separator

1200mm Skid Mounted Oilfield Poor Boy Gas Separator
1200mm Skid Mounted Oilfield Poor Boy Gas Separator
video play

Large Image :  1200mm Skid Mounted Oilfield Poor Boy Gas Separator

Product Details:
Place of Origin: Xi'an,China
Brand Name: TR Solids Control
Certification: API Certificate, ISO Certificate
Model Number: TRZYQ1200
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Pallet or wooden case
Delivery Time: 20 days after receiving deposit
Payment Terms: T/T, L/C, D/A, D/P, Western Union
Supply Ability: 300 Sets/Month
Detailed Product Description
Capacity: 320m3/h Main Body Diameter: 1200mm
Inlet Pipe: DN125mm Output Pipe: DN250mm
Gas Discharge Pipe: DN200mm Weight: 2600kg
Dimension: 2200*2200*6634mm Application: Oil & Gas Drilling, HDD
High Light:

Skid Mounted poor boy gas separator

,

Oilfield poor boy gas separator

Oilfield Skid-Mounted Mud Gas Separator With Diameter 1200mm


Product Introduction


TR Solids control is a professional manufacturer of liquid gas separator. We produce two kinds of separator-height adjustable and height fixed. When the drilling mud has gas invading, the proportion of its weight and viscosity has a greater deviation not to meet the requirements of drilling. The serious situation is that would cause well kick, and even blowout accident occurred, if not to treat it timely. So mud gas separator is necessary to avoid this accident.



Mud/Gas Separator serves as an ideal device if well blowout or kick is encountered or if operators apply under-balanced mud column in drilling processes. TR Mud/Gas Separator is primarily used to remove the enormous free gas from drilling fluids, including poisonous gases like H2S. Field data shows it is a fairly reliable and vital safety equipment.


Design Characterstics of TRZYQ Mud Gas Separator

  1. Separated gas is carried by discharge lines to safe area for combustion.
  2. Skid-Mounted and Trailer Transportable. Simplifying transport, spotting and installation.
  3. Efficient degassing performance.
  4. Separates free gas accumulations especially toxic gases from drilling mud system.
  5. Versatile Configuration. Flow line adjustments can be raised or lowered to minimize piping.
  6. Fail-safe gas delivery can be controlled by a back-pressure manifold valve in the flare line.

Technical Specifications of TRZYQ Mud Gas Separator


Model TRZYQ800 TRZYQ1000 TRZYQ1200
Capacity 180 m³/h 240 m³/h 320 m³/h
Main Body Diameter 800mm 1000mm 1200mm
Inlet Pipe DN100mm DN125mm DN125mm
Output Pipe DN150mm DN200mm DN250mm
Gas Discharge Pipe DN200mm DN200mm DN200mm
Weight 1750kg 2235kg 2600kg
Dimension 1900*1900*5700mm 2000*2000*5860mm 2200*2200*6634mm


1200mm Skid Mounted Oilfield Poor Boy Gas Separator 0



Our Mud Gas Separator is mainly used to remove the enormous free gas from drilling fluids, including poisonous gases like H2S. Currently it is widely used in Drilling Waste Management, city bored piling, trenchless HDD, oil & gas drilling, Coal Bed Gas Solids Control System, Oil Sludge Dewatering Systems, mining, Water Drilling, environment protection, Oil Mud Seperation etc.



Our principle is to offer high quality products at competitive price to benefit our customers and the industry in the long run. Our products enjoy high reputation at home and abroad. We have successfully established a stable and increased market share and we are constantly making efforts to actively expand our sales network.


Competitive Advantages


1. We offer high quality products at competitive price.
2. Shortest delivery time.
3. Flexible payment terms.
4. Timely after-sale service.
5. Most of our equipment can be replaceable with international brands.
6. Our products have been exported to Argentina, Egypt, US, Australia, Romania, Pakistan, Dubai, Abu Dhabi, Iran, India, Indonesia, Vietnam, Malaysia and many other countries.
