55KW Oil Drilling Fluid Sludge Pump 150m3/H Flow With Good Cooling Capacity

55KW Oil Drilling Fluid Sludge Pump 150m3/H Flow With Good Cooling Capacity
55KW Oil Drilling Fluid Sludge Pump 150m3/H Flow With Good Cooling Capacity
video play

Large Image :  55KW Oil Drilling Fluid Sludge Pump 150m3/H Flow With Good Cooling Capacity

Product Details:
Place of Origin: Xi'an,China
Brand Name: TR Solids Control
Certification: API Certificate, ISO9001 Certificate
Model Number: TRJQB6545
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Pallet or wooden case
Delivery Time: Within 15 days after deposit
Payment Terms: T/T, L/C, D/A, D/P, Western Union
Supply Ability: 50000 Sets / Month
Detailed Product Description
Material: Steel Color: Green
Flow: 150m3/h Lift: 45m
Motor: 55kw Weight: 980kg
Dimension: 1050*1000*1360mm Application: Oil & Gas Drilling, Trenchless HDD & Tunnelling
High Light:

drill fluid pump


cutter pump

55KW Oil Drilling Fluid Shear Pump , API Shear Pump for Sale


Product Introduction


Mud shear pump generation is uniquely design pump for shearing polymers and clays. to improve the drill fluid properties, the polymers or clays should be highly sheared before adding to the drill fluid system, if not sheered, the polymers maybe jam the strainer and will result in losing amount of polymer and increasing drilling costs, and the large-size solids in the drill fluid will harden and difficult to clear away as well. the JQB5×6-10 shear pump has proven best for applying the high shear necessary to hydrate polymers and clays and to their best properties.


Our TRJQB serial shear pump is a special pump for solid control drilling fluid additives, with engine powers of 75kw, 55kw, 45kw and 37kw, suitable for power grids of 50Hz and 60Hz, and it has both Metric and British systems as measuring standards


Design Features of Our Sheap Pump

  1. Bearings are internationally renowned brands SKF, quality assured.
  2. Oil seal adopts imported fluorine plastic seal, with good cooling capacity.
  3. Pump body adopts wear-resistant alloy cast iron, with longer service life.
  4. Pump shell wall is thick, made by casting mold. Wear-resistant, fine appearance.
  5. Material of mechanical seal is carbide alloy, its life is 5 times than normal.
  6. Using special impeller and shear board, shear efficiency> 95%.

Technical Data of TR Drilling Shear Pump


Model Flow Rate Lift Motor Weight Dimension
TRJQB6545 150m3/h 45m 55kw 980kg 1050×1000×1360mm
TRJBQ6535 100m3/h 35m 37kw 800kg 1050×1000×1230mm
TRJBQ5430 60m3/h 30m 30kw 650kg 1050×1000×1100mm
TRJBQ4330 40m3/h 30m 18.5kw 450kg 1050×1000×900mm


55KW Oil Drilling Fluid Sludge Pump 150m3/H Flow With Good Cooling Capacity 0


TR shear pump is used to treat the high property mud, making the mud to obtain good rheological properties and to cut the drilling cost as much as possible. Nowadays it is widely used in trenchless HDD, oil & gas drilling, city bored piling, tunnelling construction, Drilling Waste Management, Oil Mud Seperation, Oil Sludge Dewatering Systems, Water Drilling, Coal Bed Gas Solids Control System etc. We are welcome your inquiry of our shear pump!


TR Solids Control is absorbed in developing our product line continuously and offering innovative solutions to our customers. Our shear pumps have been exported to Russia, America, Middle East, South America, Southeast Asia, Central Asia, African, Australia, Europe etc. Our company is willing to cooperate and make common progress with friends at home and abroad with first-class products, service and reasonable prices.


Competitive Advantages


1. We offer high quality products at competitive price.
2. Shortest delivery time.
3. Flexible payment terms.
4. Timely after-sale service.
5. Most of our equipment can be replaceable with international brands.
6. Our products have been exported to Argentina, Egypt, US, Australia, Romania, Pakistan, Dubai, Abu Dhabi, Iran, India, Indonesia, Vietnam, Malaysia and many other countries.


Company Tenet


Customer's satisfaction is the highest pursuit of TR Solids Control.
