API Oil Drilling Mud Agitator In Solids Control System Good Performance

API Oil Drilling Mud Agitator In Solids Control System Good Performance
API Oil Drilling Mud Agitator In Solids Control System Good Performance
video play

Large Image :  API Oil Drilling Mud Agitator In Solids Control System Good Performance

Product Details:
Place of Origin: Xi'an,China
Brand Name: TR Solids Control
Certification: API Certificate, ISO Certificate
Model Number: TRJBQ15
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Wooden or iron pallet
Delivery Time: 10 days after receiving deposit
Payment Terms: T/T, L/C, D/A, D/P, Western Union
Supply Ability: 5000 Sets / Month
Detailed Product Description
Motor Power: 15kw Impeller Speed: 60/72r/min
Impeller Diameter: 950mm Impeller Qty: 2pcs
Ex Standard: ExdIIBt4/IECEX/A-TEX Dimension: 1330*890*747mm
Weight: 480kg Key Words: High Quality Mud Agitator For Well Drilling Fluid Mixing System, With Excellent Performance And Long Service Time
High Light:

mud tank agitator

,

fluid mixing equipment

API Good Performance Oil Drilling Mud agitator in Solids Control System



Introduction



Drilling mud agitators are the mud mixers on circulating tank. TR mud agitators includes the horizontal and vertical type. That is meant by motor mounting direction. Nowadays, more and more users prefer the helical bevel geared agitator. This is because that the helical bevel gear box will be more stable and reliable than the helical worm and wheel gearbox.

The cuttings are a major component of the harmful solid phase. To remove the harmful solid phase, they must be suspended, and then injected into the desander, desilter and centrifuge can be achieved. Useful solid phases, such as various aggravating materials (hematite powder, barite powder) and small amount of bentonite, they also need to be suspended evenly to keep stable density and other properties of the drilling fluid. Therefore, mud agitator is required to reliably and continuously operate to avoid precipitation of the solid phase.



Main Characterstics of TRJBQ Mud Agitator:

  1. Power available ranging from 3 to 22KW.
  2. The gearbox use worm gear. More reliable.
  3. Good heat exchange performance makes agitator faster cool down.​
  4. Optimized product structure, small size, compact structure.
  5. Running smoothly, small operating noise, long usage life, less wearing parts, and cost-saving.
  6. Motor and gear box will be connected by coupling directly. Agitation speed is more stable.

Specifications of Drilling Mud Agitator



Model Motor Power Impeller Speed Impeller Diameter Impeller Qty. Explosion-proof Standard Weight Dimension
TRJBQ3 3kw 60/72r/min 600mm 1



ExdIIBt4/IECEX/A-TEX

190kg 909×525×527mm
TRJBQ5.5 5.5kw 600mm 1 250kg 1072×610×588mm
TRJBQ7.5 7.5kw 650mm 2 380kg 1157×670×607mm
TRJBQ11 11kw 800mm 2 430kg 1297×740×692mm
TRJBQ15 15kw 950mm 2 480kg 1330×890×747mm
TRJBQ18.5 18.5kw 1000mm 2 740kg 1510×890×753mm
TRJBQ22 22kw 1100mm 2 780kg 1529×890×753mm
Remark Above weight and dimension exclude mud agitator shaft.



API Oil Drilling Mud Agitator In Solids Control System Good Performance 0



Main Applications



TRJBQ series mud agitator is currently used in Drilling Waste Management, city bored piling, oil & gas drilling, tunneling construction, Coal Bed Gas Solids Control System, environment protection, trenchless HDD, micro-tunneling, mining, Oil Sludge Dewatering Systems, Oil Mud Seperation, Water Drilling etc. Our mud agitators have been exported to Russia, America, Middle East, South America, Southeast Asia, Central Asia, African, Australia, Europe etc. Our company is willing to cooperate and make common progress with friends at home and abroad with first-class products, first-class service and reasonable prices.



Competitive Advantages
1. We offer high quality products at competitive price.
2. Shortest delivery time.
3. Flexible payment terms.
4. Timely after-sale service.
5. Most of our equipment can be replaceable with international brands.
6. Our products have been exported to Argentina, Egypt, US, Australia, Romania, Pakistan, Dubai, Abu Dhabi, Iran, India, Indonesia, Vietnam, Malaysia and many other countries.


Company Tenet
Customer's satisfaction is the highest pursuit of TR Solids Control.
