Product Details:
Payment & Shipping Terms:
|
| Bowl Diameter: | 355mm | Bowl Speed: | 0-3200r/min |
|---|---|---|---|
| G-Force: | 0-2035 | Differential Speed: | 0-30r/min |
| Auxiliary Motor Power: | 7.5kw | Weight: | 3200kg |
| Bowl Length: | 1250mm | Capacity: | 40m³/h |
| Separation Point: | 2-7μm | Main Drive Motor: | 37kw |
| Ex Standard: | ExdIIBt4/IECEX/A-TEX | Dimension: | 2600*1620*1750mm |
| High Light: | drilling mud decanter centrifuge,liquid solid separation centrifuge |
||
High Speed Large Capacity Decanter Centrifuge for Drilling Waste Management
Main Characteristic of Decanter Centrifuge
Introduction
Decanter centrifuge is ideal choices for separating particles in drilling mud. It's mainly used to process unweighted and weighted, water-based and oil-based drilling fluids (muds). Mechanical energy is utilized to increase the gravitational force exerted on solids that are present in the mud system.oilfield Decanting Centrifuge are able to apply over 3,000 G-forces on the liquid/solids mixture, which separates the heavier solids from the lighter solids. Additionally, high G-forces separate fine solids from liquid.
Taking advantage of the principle that the light liquid, heavy liquid and solid phase, with different density and mutually insoluble in the mixed liquid,gain different sedimentation speed in the centrifugal force field or gravity force field, separating stratification or causing the solid particles in the liquid to deposit can be achieved.
Parameters of TRLW Series Decanting Centrifuge
| Model | TRLW600B-1 | TRLW450N-1 | TRLW450N-2 | TRLW355N-1 | TRLW355NB-1 |
| Bowl Diameter | 600mm | 450mm | 450mm | 355mm | 355mm |
| Bowl Length | 1500mm | 1000mm | 1250mm | 1250mm | 1250mm |
| Bowl Speed | 2200r/min | 2200r/min | 3200r/min | 3200r/min | 0~3200r/min |
| Max Capacity | 90m³/h | 50m³/h | 50m³/h | 40m³/h | 40m³/h |
| G-Force | 815 | 815 | 2035 | 2035 | 0~2035 |
Separation | 5~7μm | 5~7μm | 5~7μm | 2~5μm | 2~7μm |
Gear Box | 40r/min | 40r/min | 30r/min | 30r/min | 0~3030r/min |
Gear Box | 35:1 | 57:1 | |||
Main Motor | 55kw | 30kw | 37kw | 30kw | 37kw |
Auxiliary | 15kw | 7.5kw | 7.5kw | 7.5kw | 7.5kw |
| EX Standard | ExdIIBt4/IECEX/A-TEX | ||||
| Weight | 4800kg | 2700kg | 3200kg | 2900kg | 3200kg |
| Dimension | 2900*1900 | 2600*1860 | 2600*1860 | 2600*1620 | 2600*1620 |
(Note: Rotary speed can be adjustable as per user's requirements)
Application
TRLW series decanter centrifuge is widely used in oil & gas drilling, Drilling Waste Management, trenchless HDD, tunneling construction, environment protection, Coal Bed Gas Solids Control System, Oil Mud Seperation, mining, chemical Industry, food industry, Pharmaceutical Industry, Oil Sludge Dewatering Systems etc.
Competitive Advantages
1. We offer high quality products at competitive price.
2. Shortest delivery time.
3. Flexible payment terms.
4. Timely after-sale service.
5. Most of our equipment can be replaceable with international brands.
6. Our products have been exported to Argentina, Egypt, US, Australia, Romania, Pakistan, Dubai, Abu Dhabi, Iran, India, Indonesia, Vietnam, Malaysia and many other countries.
