Oil Field Drilling Mud Gas Separator 240m3/H Capacity TRZYQ1000 Large Capacity

Oil Field Drilling Mud Gas Separator / H2S Mud Gas Separator Gas-Buster

Introduction

TRZYQ series mud gas separator is the special equipment to treat the gas cut drilling mud. The gas cut drilling mud will cause density and viscosity of drilling mud greatly deviate from normal parameter, it can not meet the requirement of drilling will cause of kick and blowout accident occurred. Mud gas separator combined with flare ignition device can process the gas-cut drilling mud effectively and timely.

For oil and gas well drilling, we usually set mud gas separator ahead of shale shakers. The drilling mud out of well bore will flow into separator via the chock manifold. After degassed, fluids will flow out of separator into shaker by pass or possum belly. Mud gas separator will help to get rid of large quantity invading gas. These are harmful and toxic gases may lead blow out.

Application

TR Mud Gas Separator is mainly used to remove the enormous free gas from drilling fluids, including poisonous gases like H2S. Currently it is widely used in Oil Sludge Dewatering Systems, city bored piling, Oil Mud Seperation, oil & gas drilling, Drilling Waste Management, trenchless HDD, Coal Bed Gas Solids Control System, mining,  Water Drilling, environment protection etc.

Advantages of TRZYQ Series Mud Gas Separator

1. Efficient degassing performance.
2. Reduces Hazardous Gas Threat.
3. Separates free gas accumulations especially toxic gases from drilling mud system.
4. Fail-safe gas delivery can be controlled by a back-pressure manifold valve in the flare line.
5. Versatile Configuration. Flow line adjustments can be raised or lowered to minimize piping.
6. Skid-Mounted and Trailer Transportable. Simplifying transport, spotting and installation.


Technical Sheet of TRZYQ Series Mud Gas Separator





Competitive Advantages
1. We offer high quality products at competitive price.
2. Shortest delivery time.
3. Flexible payment terms.
4. Timely after-sale service.
5. Most of our equipment can be replaceable with international brands.
6. Our products have been exported to Argentina, Egypt, US, Australia, Romania, Pakistan, Dubai, Abu Dhabi, Iran, India, Indonesia, Vietnam, Malaysia and many other countries.
