Stable Liquid Gas Separator 180m3/H Capacity DN150mm Output Pipe ISO

Stable Liquid Gas Separator 180m3/H Capacity DN150mm Output Pipe ISO
Stable Liquid Gas Separator 180m3/H Capacity DN150mm Output Pipe ISO

Large Image :  Stable Liquid Gas Separator 180m3/H Capacity DN150mm Output Pipe ISO

Product Details:

Place of Origin: Xi'an,China
Brand Name: TR Solids Control
Certification: API Certificate, ISO Certificate
Model Number: TRZYQ800

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Pallet or wooden case
Delivery Time: 20 days after receiving deposit
Payment Terms: T/T, L/C, D/A, D/P, Western Union
Supply Ability: 100 Sets/Month
Detailed Product Description
Capacity: 180m3/h Main Body Diameter: 800mm
Inlet Pipe: DN100mm Output Pipe: DN150mm
Gas Discharge Pipe: DN200mm Weight: 1750kg
Dimension: 1900*1900*5700 Mm Key Words: Oil & Gas Drilling Mud Gas Separator, Trenchless HDD Mud Gas Separator
High Light:

poor boy gas separator

,

mud separator

Hot Sale Drilling Mud Gas Separator for Liquid And Gas , Oilfield Liquid Gas Separator

Introduction



TRZYQ series Mud gas separator(Poor Boy Degasser) is a special equipment to handle invaded gas of drilling fluids. Density and viscosity of drilling fluid greatly is influenced by the invaded gas, sometimes it will lead to well kick or blowout accident. Mud gas Separator combined with the Flare Ignition Device can be used to assure the drilling process smoothly.



Liquid Gas Separator serves as an ideal device if well blowout or kick is encountered or if operators apply under-balanced mud column in drilling processes. TRZYQ series mud ags separator is primarily used to remove the enormous free gas from drilling fluids, including poisonous gases like H2S. Field data shows it is a fairly reliable and vital safety equipment.


Application

Our TRZYQ Mud Gas Separator is mainly used to get rid of enormous free gas from drilling fluids, including poisonous gases like H2S. Currently it is widely used in Coal Bed Gas Solids Control System, Drilling Waste Managementcity bored piling, oil & gas drilling, trenchless HDD, Oil Mud Seperation, Oil Sludge Dewatering Systems, mining, Water Drilling, environment protection etc.

Features of TRZYQ Series Mud Gas Separator

  1. Reduces Hazardous Gas Threat.
  2. Efficient degassing performance.
  3. Skid-Mounted and Trailer Transportable. Simplifying transport, spotting and installation.
  4. Fail-safe gas delivery can be controlled by a back-pressure manifold valve in the flare line.
  5. Separates free gas accumulations especially toxic gases from drilling mud system.
  6. Versatile Configuration. Flow line adjustments can be raised or lowered to minimize piping.


Specification of TRZYQ Series Mud Gas Separator


Model TRZYQ800 TRZYQ1000 TRZYQ1200
Capacity 180 m³/h 240 m³/h 320 m³/h
Main Body Diameter 800mm 1000mm 1200mm
Inlet Pipe DN100mm DN125mm DN125mm
Output Pipe DN150mm DN200mm DN250mm
Gas Discharge Pipe DN200mm DN200mm DN200mm
Weight 1750kg 2235kg 2600kg
Dimension 1900*1900*5700mm 2000*2000*5860mm 2200*2200*6634mm


Stable Liquid Gas Separator 180m3/H Capacity DN150mm Output Pipe ISO 0

Competitive Advantages
1. We offer high quality products at competitive price.
2. Shortest delivery time.
3. Flexible payment terms.
4. Timely after-sale service.
5. Most of our equipment can be replaceable with international brands.
6. Our products have been exported to Argentina, Egypt, US, Australia, Romania, Pakistan, Dubai, Abu Dhabi, Iran, India, Indonesia, Vietnam, Malaysia and many other countries.


Company Tenet
Customer's satisfaction is the highest pursuit of TR Solids Control.
