Reliable Oilfield Drilling Mud Tank Agitator with 600mm Diameter Impeller

Reliable Oilfield Drilling Mud Tank Agitator with 600mm Diameter Impeller
Reliable Oilfield Drilling Mud Tank Agitator with 600mm Diameter Impeller
video play

Large Image :  Reliable Oilfield Drilling Mud Tank Agitator with 600mm Diameter Impeller

Product Details:
Place of Origin: Xi'an,China
Brand Name: TR Solids Control
Certification: API Certificate, ISO Certificate
Model Number: TRJBQ3
Payment & Shipping Terms:
Minimum Order Quantity: 1 SET
Price: Negotiable
Packaging Details: Wooden or iron case
Delivery Time: 10 days after receiving deposit
Payment Terms: T/T, L/C, D/A, D/P, Western Union
Supply Ability: 5000 Sets / Month
Contact Now
Detailed Product Description
Motor Power: 3kw Impeller Speed: 60/72r/min
Impeller Diameter: 600mm Impeller Qty: 1pcs
Ex Standard: ExdIIBt4/IECEX/A-TEX Dimension: 909*525*527mm
Weight: 190kg Key Words: High Quality 3kw Mud Agitator For Well Drilling Fluid Mixing System, With Excellent Performance And Long Service Time
High Light:

mud tank agitator

,

mud mixer machine

Reliable Oilfield Drilling Mud Tank Agitator with 600mm Diameter Impeller



Product Introduction



Drilling mud agitator is mainly used for stirring and mixing of drilling fluids to prevent the solid particles from depositing in its tank circulation system, making the performance of circulating drilling fluid stable, and mixing evenly. In order to keep the uniformity of drilling fluids and to suspend the solid particles, it is necessary to install mud agitator on the circulating tank. Stirring plays a very important role in accelerating the reaction, dissolution and wetting of drilling fluids (eg. bentonite, barite) and chemical additives. Stirring increases the contact area between the phases, and allows the two phases to interact with each other at a greater speed.

TR Solids Control provides both vertical and horizontal mud agitator. Horizontal agitator is divided into coupling type and direct type agitator. If you need a horizontal agitator, we recommend you use a direct type agitator. Our mud agitator has reasonable price and superior quality.



Main benefits of TRJBQ series mud agitator

  1. The gearbox use worm gear. More reliable.
  2. Optimized product structure, compact structure.
  3. Running smoothly, less wearing parts, and cost-saving.
  4. Motor and gear box will be connected by coupling directly. Agitation speed is more stable.
  5. Good heat exchange performance makes agitator faster cool down.
  6. Spraying Processing: grinding and sandblasting with base coating, middle coating and finish coating.

Technical Data of TRJBQ Series Mud Agitator



Model Motor Power Impeller Speed Impeller Diameter Impeller Qty. Explosion-proof Standard Weight Dimension
TRJBQ3 3kw 60/72r/min 600mm 1



ExdIIBt4/IECEX/A-TEX

 190kg 909×525×527mm
TRJBQ5.5 5.5kw 600mm 1 250kg 1072×610×588mm
TRJBQ7.5 7.5kw 650mm 2 380kg 1157×670×607mm
TRJBQ11 11kw 800mm 2 430kg 1297×740×692mm
TRJBQ15 15kw 950mm 2 480kg 1330×890×747mm
TRJBQ18.5 18.5kw 1000mm 2 740kg 1510×890×753mm
TRJBQ22 22kw 1100mm 2 780kg 1529×890×753mm
Remark Above weight and dimension exclude mud agitator shaft.



Reliable Oilfield Drilling Mud Tank Agitator with 600mm Diameter Impeller 0



Our mud agitators have been exported to Russia, America, Middle East, South America, Southeast Asia, Central Asia, African, Australia, Europe etc. Our company is willing to cooperate and make common progress with friends at home and abroad with first-class products, first-class service and reasonable prices. Welcome friends from all over the world to come to visit our factory and guidance our work.



Competitive Advantages



1. We offer high quality products at competitive price.
2. Shortest delivery time.
3. Flexible payment terms.
4. Timely after-sale service.
5. Most of our equipment can be replaceable with international brands.
6. Our products have been exported to Argentina, Egypt, US, Australia, Romania, Pakistan, Dubai, Abu Dhabi, Iran, India, Indonesia, Vietnam, Malaysia and many other countries.


Company Tenet
Customer's satisfaction is the highest pursuit of TR Solids Control.
