Flow Rate 10m3/h API Spec Oilfield Screw Pump , Solids Control Screw Pump
Introduction
The screw pump is mainly used to deliver drilling fluid to the decanter centrifuge. Unlike other sewage pumps, it can deliver the mud to the centrifuge without shearing and stirring the drilling fluid. In addition to this, it is also used for drilling waste disposal and cuttings for conveying wet mud.
The screw pump can be driven by a coupling, and can also be adjusted by a variable speed motor, V-belt, gearbox, etc. The rotor and stator are the wearing parts of the pump, which are easy to replace. The stator is made of synthetic rubber material. It has special advantages over other pumps when conveying fluids with high viscosity and hard suspended particles. Our TRG series screw pumps have few accessories, compact structure, small volume and easy maintenance.
Application
TRG series screw Pump is widely used in oil & gas drilling, tunnelling construction, trenchless HDD, city bored piling, Coal Bed Gas Solids Control System, Drilling Waste Management, Oil Mud Seperation, Oil Sludge Dewatering Systems, Water Drilling, environment protection, shipbuilding industry, brewing Industry etc.
Features of TRGSeries Shear Pump
1. High suction height, low noise. No leakage, no temperature rise when conveying liquid.
2. Large working speed range. Flow and pressure can be adjustable.
3. Rotor and stator are vulnerable parts. They are easy to replace.
4. Long operational life with reliable performance.
5. Stable flow rate and pressure. No pulse.
6. Less accessories, compact structure and easy maintenance.
7. Wide application range. Can convery all flowable media.
Technical Data of TRG Series Screw Pump
| Model | Flow Rate | Pressure | Power |
Inlet (Inch) |
Outlet (Inch) |
Ex Standard |
Weight (Kg) |
Dimension |
| TRG10A-040 | 10m³/h | 0.3Mpa | 4kw | 3 | 3 | ExdIIBt4/IECEX/A-TEX | 245 | 2245×320×550mm |
| TRG20A-055 | 20m³/h | 5.5kw | 3 | 3 | 323 | 2450×340×562mm | ||
| TRG30A-075 | 30m³/h | 7.5kw | 4 | 4 | 386 | 2761×370×600mm | ||
| TRG40A-110 | 40m³/h | 11kw | 5 | 5 | 454 | 3270×370×665mm | ||
| TRG50A-110 | 50m³/h | 11kw | 5 | 5 | 608 | 3790×400×782mm | ||
| TRG60A-150 | 60m³/h | 15kw | 5 | 5 | 649 | 3322×550×740mm | ||
| TRG70A-220 | 70m³/h | 22kw | 6 | 6 | 875 | 3740×420×785mm | ||
| TRG80A-220 | 80m³/h | 22kw | 6 | 6 | 875 | 3740×420×785mm | ||
| TRG90A-220 | 90m³/h | 22kw | 6 | 6 | 875 | 3740×420×785mm |
Competitive Advantages
1. We offer high quality products at competitive price.
2. Shortest delivery time.
3. Flexible payment terms.
4. Timely after-sale service.
5. Most of our equipment can be replaceable with international brands.
6. Our products have been exported to Argentina, Egypt, US, Australia, Romania, Pakistan, Dubai, Abu Dhabi, Iran, India, Indonesia, Vietnam, Malaysia and many other countries.
Company Tenet
Customer's satisfaction is the highest pursuit of TR Solids Control.
