Drilling Fluids Vacuun Degasser 1000mm 7.5kw 360m3/H High Efficiency

China Xi'an TianRui Petroleum Machinery Equipment Co., Ltd. certification
China Xi'an TianRui Petroleum Machinery Equipment Co., Ltd. certification
Professional solids control manufacturer. Their Product replacement shaker screens have long service time and good treatment. They help us a lot!

—— Mr. Samir

I purchased 10 pcs TRSB8*6-12J centrifugal pump from TR Solids Control. They are good-looking and really have good quality and considerate after sales service!

—— Mr. Warren

We ordered a set of mud system for our oilfield drilling field, TR product showed good performance in the site. We like that very much!

—— Diego Olbrich

TR shaker screens have top quality and good price. We have been purchasing them from TR for more than 4 years.

—— Nghiem Thic Hai

Good company with nice service and high quality and high reputation. One of our reliable supplier , goods are delivered in time and nice package.

—— Hossein Jafari

Thanks for your good after-sale service. Excellent training and technology support helps me a lot.

—— Ms. Crina

We start use TRZS703 Shale Shaker since 2012, now we have 8 sets working in our customer's oilfield site, perfect machine with reasonable price.

—— S. A. Kazi

I'm Online Chat Now

Drilling Fluids Vacuun Degasser 1000mm 7.5kw 360m3/H High Efficiency

Drilling Fluids Vacuun Degasser 1000mm 7.5kw 360m3/H High Efficiency
Drilling Fluids Vacuun Degasser 1000mm 7.5kw 360m3/H High Efficiency Drilling Fluids Vacuun Degasser 1000mm 7.5kw 360m3/H High Efficiency Drilling Fluids Vacuun Degasser 1000mm 7.5kw 360m3/H High Efficiency

Large Image :  Drilling Fluids Vacuun Degasser 1000mm 7.5kw 360m3/H High Efficiency

Product Details:
Place of Origin: Xi'an,China
Brand Name: TR Solids Control
Certification: API Certificate, ISO9001 Certificate
Model Number: TRZCQ360
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Iron or nude package
Delivery Time: Within 25 days after deposit
Payment Terms: T/T, L/C, D/A, D/P, Western Union
Supply Ability: 3000 Sets/Month
Detailed Product Description
Body Diameter: 1000m Capacity/Flow Rate: 360m3/h
Vacuum Degree: -0.03~-0.045Mpa Transmission Ratio: 1.72
Degassing Efficiency: ≥95% Main Power: 37kw
Vacuum Pump Power: 7.5kw Impeller Speed: 880r/min
Weight: 1800kg Dimension: 2400*1500*1850mm
High Light:

Mud Circulation System Vacuum Degasser

,

1000mm Vacuum Degasser

,

Drilling Fluids Vacuum Degassing System

Drilling Rig Part Mud Vacuum Degassing System / Oilfield Vacuum Degasser



Introduction



Vacuum Degasser is also called mud/Gas separator. Mud/gas separators (Degasser) is the first units of arranged to treat drilling mud. As such, they process all of the drilling mud from the flow line before the mud reaches the primary . The units have no moving parts and rely on the density difference between the gas and the mud for removal. The process is simple, yet very effective for well.



TRZCQ series vacuum Degasser is a special-purpose device and a new type one for gas treatment in drilling fluids. It can get rid of various invasive gas in drilling fluids quickly. Degasser is very important for stabilizing mud viscosity, returning mud gravity and reducing drilling cost. It can be used as a heavy-power agitator and supported applicable to all types of mud circulation system.



Main Benefits of TR Vacuum Degasser

  1. Scientific and reasonable design for structure achieves effective separation of gas and liquid.
  2. Gas-water separator in vacuum degasser saves water and environment-friendly.
  3. TR vacuum degasser has high degassing efficiency up to 95%.
  4. Self-priming device enables it to pump drilling fluids without centrifugal pump.
  5. Belt drive guarantees the long time working time without trouble.​
  6. Water ring type of vacuum pump work is suitable for flammable and explosive gas suction.

Parameters of Our Vacuum Degasser



Model TRZCQ240 TRZCQ270 TRZCQ300 TRZCQ360
Body Diameter 700mm 800mm 900mm 1000mm
Capacity 240 m³/h 270 m³/h 300 m³/h 360 m³/h
Vacuum Degree -0.030-0.045Mpa -0.030-0.050Mpa -0.030-0.045Mpa -0.030-0.045Mpa
Transmission Ratio 1.68 1.68 1.68 1.72
Degassing Efficiency ≥95% ≥95% ≥95% ≥95%
Motor Power 15kW 22kW 30kW 37Kw
Vacuum Pump Power 2.2kW 3kW 4kW 7.5kW
Impeller Speed 860r/min 870r/min 876r/min 880r/min
Dimension 1750×860×1500mm 2000×1000×1670mm 2250×1330×1650mm 2400×1500×1850mm
Weight 1100kg 1350kg 1650kg

1800kg



































Drilling Fluids Vacuun Degasser 1000mm 7.5kw 360m3/H High Efficiency 0



If you want to buy Vacuum Degasser, you just need to be prepared to answer these following questions:
1. What is the handling capacity?Such as 240m­­­3/h,270m­­­3/h,300m­­­3/h,360m­­­3/h.
2. What is the diameter of the main body? 700mm,800mm,900mm,1000mm.
3. What is the power of the Vacuum pump? Such as 2.2 kw, 3 kw,4kw,kw
4. What is the power of the main motor? Such as 15kw,22kw,30kw,37kw.



Our Services


1. Customized configurations available.
2. Engineers available to service machinary overseas.
3. Productive process are visible by vedio&pictures.
4. Fast reaction to clients' needs.
5. Plenty of goods&spare parts.



Competitive Advantages



1. We offer high quality products at competitive price.
2. Shortest delivery time.
3. Flexible payment terms.
4. Timely after-sale service.
5. Most of our equipment can be replaceable with international brands.
6. Our products have been exported to Argentina, Egypt, US, Australia, Romania, Pakistan, Dubai, Abu Dhabi, Iran, India, Indonesia, Vietnam, Malaysia and many other countries.
