Small Footprint Piling Desander For Construction Industry 200m3/H

Small Footprint Piling Desander For Construction Industry 200m3/H
Small Footprint Piling Desander For Construction Industry 200m3/H
video play

Large Image :  Small Footprint Piling Desander For Construction Industry 200m3/H

Product Details:
Place of Origin: Xi'an,China
Brand Name: TR Solids Control
Certification: API & ISO Certified
Model Number: TRZX-200/50
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Wooden case or by container
Delivery Time: 25 days
Payment Terms: T/T, L/C, D/A, D/P, Western Union
Supply Ability: 150 Set / Month
Detailed Product Description
Fluid Capacity: ≤200m3/h Separation Point: 50μm
Shale Shaker: TRZS705 Vibration Motor: 1.5kw*2
Matching Pump: TRSB6*5-13J(45kw) Hydrocyclones: DN250*2pcs
Tank Dimension: 4000*2200*1300mm System Dimension: 4000*2330*2850mm
Screen: Double Layers Material: Cast Steel
High Light:

Footprint Piling Mud Desander

,

Construction Industry Drilling Mud Desander

,

200m3/H Drilling Mud System

200m3/h Small Footprint Desanding Plant for Bored Pile and HDD



Product Introduction



Desanding Plant is the economic way for the mud recycling, it is popular for Bored Pile Slurry desanding plant, TBM slurry treatment, HDD (trenchless) as well as water well drilling etc.



The Mud Recycling System, self-developed by TR Solids Control, mainly used to recycle the slurry essence piling constructions of circulation & counterflush drilling and shied in constructions of slurry balanced, can decrease the slurry discharge, cut tool-sticking accidents, and improve the drilling efficiency. Double screen mesh was adopted in filter system to improve working efficiency by 50% compared with the traditional single mesh one. Meanwhile, our desander has the properties of simple operation, easy maintenance as well as outstanding cleaning and purifying ability, long service life and high reliability.



TR Solids Control can design and manufacture the different types and capacity desanding plants accroding to customer requirments and the actual construction environment. Capacity: 50m3/h 120m3/h 150m3/h 180m3/h 240m3/h 360m3/h.



Main Benefits of TR Bored Piling Desanding Plant

  1. It can improve quality and working efficiency of pore making in the pile foundation.
  2. Effective separation of soil crusts, pore-forming efficiency is enhanced.
  3. Mud reuse saves mud making materials and reduces construction cost.
  4. High mud handling capacity, sand can be removed efficiently.
  5. The equipment for modular design and compact structure, making it easy to put in the construction and convenient to move.
  6. Mud closed-circuit circulation mode and low ballast material moisture content are helpful to reduce environment pollution.

Technical Specifications of TR Bored Pile Desanding Plant



Model TRZX-50/25 TRZX-100/50 TRZX-200/50
Fluid Capacity ≤50m³/h ≤100m³/h ≤200m³/h

Sludge Treatment Capacity

≤26T/h ≤50m³/h ≤50m³/h
Separation Point 25μm 50μm 50μm
Shale Shaker TRZS753 TRZS753 TRZS705

Screen Area

Upper:700×1250

Bottom:750×900×2

Upper:700×1250

Bottom:750×900×2

Upper:750×900×2

Bottom:700×1250×3

Vibration Motor

1.0kw×2 1.0kw×2 1.5KW×2
Matching Pump TRSB4×3-12(15KW) TRSB5×4-13(30KW) TRSB6×5-13J(45KW)
Matching Hydrocyclone DN100×4 DN250×1 DN250×2
Tank Dimension 2.1x1.5x2.6m 3.05x2.0x1.2m 3.6x2.1x1.2m
Dimension   3.12x2.2x2.38m 3.7x2.2x2.54m

Small Footprint Piling Desander For Construction Industry 200m3/H 0

As TR Manufacture shale shakers, desanders, desilters, decanter centrifuges. So TR Solids Control is able to provide complete solutions for TBM Desanding plant, desanding unit project. The shale shaker for separation coarse solids, the desander for separation sands, the desilter for separation silts, the mechanical centrifuge for separation fine solids.The chemically enhanced technology with decanter centrifuge for separation ultra fine solids to discharge water.


And we have many years of history in the petroleum equipment industry. Our main products include solid control equipment, drilling equipment, oil production equipment, wellhead equipment, well control equipment, downhole tools, OCTG pipe, vavle & pipe fitting and oilfield tools. Currently, our products is already exported to America, Middle East, Australia,Africa and 20 other countries and regions.



Our company has always focused on research, development and innovation. TR will initiate the second phase of our development strategy. Our company regards "reasonable prices, efficient production time and good after-sales service" as our tenet. We hope to cooperate with more customers for mutual development and benefits. We welcome potential buyers to contact us.



Competitive Advantages


1. We offer high quality products at competitive price.
2. Shortest delivery time.
3. Flexible payment terms.
4. Timely after-sale service.
5. Most of our equipment can be replaceable with international brands.
6. Our products have been exported to Argentina, Egypt, US, Australia, Romania, Pakistan, Dubai, Abu Dhabi, Iran, India, Indonesia, Vietnam, Malaysia and many other countries.


Company Tenet
Customer's satisfaction is the highest pursuit of TR Solids Control.
