PLC Waste Management Oilfield Api Mud Circulation System

PLC Waste Management Oilfield Api Mud Circulation System
PLC Waste Management Oilfield Api Mud Circulation System
video play

Large Image :  PLC Waste Management Oilfield Api Mud Circulation System

Product Details:
Place of Origin: Xi'an, China
Brand Name: TR Solids Control
Certification: API Certificate, ISO Certified
Model Number: TRDWM-1
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Wooden case or by container
Delivery Time: 30 days
Payment Terms: T/T, L/C, D/A, D/P, Western Union
Supply Ability: 100 Set / Month
Detailed Product Description
Drying Shaker: TRZS585*1pc High Speed Centrifuge: TRLW355N-1*1pc
Sand Pump: TRSB4*3-11J*2pcs Screw Conveyor: TRL350*3000
Vertical Cutting Dryer: TRCD930C*1pc Centrifuge Pump: 80YZ50-20B81pc
Medium: OIl-based Mud Package: By Container
High Light:

API Mud Circulation System

,

Oilfield Mud Circulation System

,

PLC Drilling Fluid Tank

Oil Based Drill Cuttings Treatment / Oil and Gas Drilling Waste Management



Product Overview


Mud solid control system(Drilling Fluid Circulation Tank, Mud circulation tank) is an indispensable part of modern drilling. It can ensure that the drilling rig in the drilling process of the normal circulation and performance of the slurry, the product mainly by the explosion-proof power, lighting distribution and control devices, double-excited double-layer new drilling fluid shale shaker, centrifugal vacuum degassing, desilter,desander, horizontal centrifuges, vertical sand pumps, mud mixers, mixed dosing funnels, and tanks can be used to separate, agitate and reserve the drilling fluid to meet the drilling Engineering needs. The company, developed a set of solid control system, has ZJ40J, ZJ50D, ZJ70D, ZJ32, ZJ20B7 and other types of rig supporting.



Our oil-based drilling waste management is mainly divided into waste drying collection unit, liquid phase separation unit. As for disposal of waste mud, we need to add gel breaker processing unit.



Main Advantages of Drilling Waste Management Scheme



  • High-capacity, continuous feed units have the throughput to keep up with drilling.
  • Different kinds of screens can meet various operation requirement.
  • Explosion-proof motors and control panels can be certified with CE/ATEX.
  • Programmable Logic Controller (PLC), with automatic warning indicators, monitors temperature, torque, oil flow and operating hours.
  • Tungsten-carbide-coated, independently adjustable flights reduce wear and ensure optimal tolerance.
  • Handrail and walkways is convenient for operators to do routine maintenance work, that can reduce risk to personnel.



Equipment List Details of Our Drilling Waste Management



S/N S/N Description
1 Vertical Cuttings Dryer TRCD930 with option for VFD or fixed speed
2 Decanter Centrifuge TRGLW355Centrifuge 14inch bowl,Optional model as below:
TRGLW355 Centrifuge with VFD drive.
TRGLW355 standard with fixed speed
3 Screw Pump Two sets TRG30A-075 Screw Pump with capacity:30m³/h for each pump.
One for taking fluids from catching tank to feed the decanter centrifuge,the other for flushing the Vertical dryer.
4 Skid with catching tank Fast move skid for mounting all the equipment
One Catching tank with capacity:4m³ for catching fluid from vertical cuttings dryer.
5 Telescopic Skid Two telescopic skid with walkways and handrails for safe operation.
One for mounting the decanter centrifuge to a higher position in order to allow the centrifuge discharged fluids feed to active mud system by gravity.
The other telescopic skid for mounting and adjusting the height of the vertical cutting dryer to allow the discharge of drying cuttings
6 Electric Cradle 0.5 Tons electric cradle for lifting the components of vertical dryer
7 Electric Control System Two lighting system,electrical control boxes and cables and plugs for operation the complete system.



PLC Waste Management Oilfield Api Mud Circulation System 0


All products purchased in our company are guaranteed to keep in good repair for one year. If quality problems happen in guarantee period, our company will maintain for free. Additionally, our company provides technical support and fittings for life. After-sales service isn't restricted by time and we will assign technical personnel to solve your problems immediately after receiving telephone and hear feedback idea of users and deal with them in time. If you are caught in some problems when using our products, welcome to contact us at any time.


Competitive Advantages


1. We offer high quality products at competitive price.
2. Shortest delivery time.
3. Flexible payment terms.
4. Timely after-sale service.
5. Most of our equipment can be replaceable with international brands.
6. Our products have been exported to Argentina, Egypt, US, Australia, Romania, Pakistan, Dubai, Abu Dhabi, Iran, India, Indonesia, Vietnam, Malaysia and many other countries.


Company Tenet
Customer's satisfaction is the highest pursuit of TR Solids Control.
