Wear Resistant API Oilfield 5.5KW Submersible Mud Pump

Wear Resistant API Oilfield 5.5KW Submersible Mud Pump
Wear Resistant API Oilfield 5.5KW Submersible Mud Pump
video play

Large Image :  Wear Resistant API Oilfield 5.5KW Submersible Mud Pump

Product Details:
Place of Origin: Xi'an,China
Brand Name: TR Solids Control
Certification: API Certificate, ISO Certificate
Model Number: 80YZ50-20B
Payment & Shipping Terms:
Minimum Order Quantity: 1 Pc
Price: Negotiable
Packaging Details: Pallet or wooden case
Delivery Time: 10 days after deposit
Payment Terms: T/T, L/C, D/A, D/P, Western Union
Supply Ability: 1000 Sets Per Month
Detailed Product Description
Model: 80YZ50-20B Flow: 40m3/h
Lift: 16m Speed: 1440r/min
Motor: 5.5kw Appllication: Oil & Gas Drilling, Trechless HDD & Tunnel, Drilling Waste Management
High Light:

submersible sludge pump


submersible sewage pump

5.5KW 80YZ50-20B API Oilfield Solid Control Submersible Slurry Pump


Product Introduction


Submersible slurry pump can transport large particles of solid particles. The standard length of pump inserting liquid is 1.3 meter, and it can be equipped with a suction tube if required. The drive is mounted on the motor base by a vertical motor and connected to the pump with a coupling. The pump rotates clockwise from the direction of the motor.


TR submersible slurry pump has vertical single stage and single suction system in overhung structure, adopting wear-resistant alloy material and can convey the mud / slurry with bigger solid particles. Single screw pump is used in all fields widely to feel kinds of medium, running at a constant pressure continuously, without pulse and damage when feeding medium, and change the gauging aim through adjusting rotation speed.


Key Benefits of TR Submersible Slurry Pump

  1. Submerge length can be customizable.
  2. Enough rigidity in submerged parts of the shaft.
  3. Impeller is semi-open type.
  4. Compact design covers small space.
  5. Could convey the medium containing solid particles with larger density.
  6. No bearing between impeller and pump for less repair cost.
  7. Vertical motor is installed on motor base, connecting the pump by coupling.

Technical Data of YZ Series Submersible Slurry Pump


Model Flow Lift Speed Motor
50YZ25-12 25m3/h 12m 1430r/min 3kw
50YZ20-18 20m3/h 18m 1430r/min 4kw
80YZ50-20B 40m3/h 16m 1440r/min 5.5kw
80YZ50-20 60m3/h 17.5m 1440r/min 7.5kw
80YZ80-20 90m3/h 22m 1460r/min 11kw
100YZ100-30A 75m3/h 30m 1470r/min 18.5kw
100YZ100-30 60m3/h 36m 1470r/min 22kw
100YZ160-38B 82m3/h 33m 1480r/min 30kw
100YZ120-60 120m3/h 40m 1480r/min 45kw
150YZ250-40A 135m3/h 35m 1480r/min 55kw
150YZ250-40B 120m3/h 28m 1480r/min 37kw


Wear Resistant API Oilfield 5.5KW Submersible Mud Pump 0


Delivery time:
1. Warehouse machine: 1 days after 100% payment.
2. booked machine: 30-45days after 30% payment.
Welcome oversea rig manufacturer to cooperate with us.


After Service
1.Warranty Period: one year (Attention: Machine's warranty range don't include damageable Spare Parts;
For other parts,providing new free parts for clients in warranty period).
2. Supporting for technique for stainless steel mixing water tank.
3.Free train using machine and free repair.


Competitive Advantages

1. We offer high quality products at competitive price.
2. Shortest delivery time.
3. Flexible payment terms.
4. Timely after-sale service.
5. Most of our equipment can be replaceable with international brands.
6. Our products have been exported to Argentina, Egypt, US, Australia, Romania, Pakistan, Dubai, Abu Dhabi, Iran, India, Indonesia, Vietnam, Malaysia and many other countries.
