18.5kw Motor Drilling Rig Equipment Shear Type Pump High Efficiency ISO 9001

China Xi'an TianRui Petroleum Machinery Equipment Co., Ltd. certification
China Xi'an TianRui Petroleum Machinery Equipment Co., Ltd. certification
Professional solids control manufacturer. Their Product replacement shaker screens have long service time and good treatment. They help us a lot!

—— Mr. Samir

I purchased 10 pcs TRSB8*6-12J centrifugal pump from TR Solids Control. They are good-looking and really have good quality and considerate after sales service!

—— Mr. Warren

We ordered a set of mud system for our oilfield drilling field, TR product showed good performance in the site. We like that very much!

—— Diego Olbrich

TR shaker screens have top quality and good price. We have been purchasing them from TR for more than 4 years.

—— Nghiem Thic Hai

Good company with nice service and high quality and high reputation. One of our reliable supplier , goods are delivered in time and nice package.

—— Hossein Jafari

Thanks for your good after-sale service. Excellent training and technology support helps me a lot.

—— Ms. Crina

We start use TRZS703 Shale Shaker since 2012, now we have 8 sets working in our customer's oilfield site, perfect machine with reasonable price.

—— S. A. Kazi

I'm Online Chat Now

18.5kw Motor Drilling Rig Equipment Shear Type Pump High Efficiency ISO 9001

18.5kw Motor Drilling Rig Equipment Shear Type Pump High Efficiency ISO 9001
18.5kw Motor Drilling Rig Equipment Shear Type Pump High Efficiency ISO 9001
video play

Large Image :  18.5kw Motor Drilling Rig Equipment Shear Type Pump High Efficiency ISO 9001

Product Details:
Place of Origin: Xi′an, China
Brand Name: TR Solids Control
Certification: ISO 9001:2008
Model Number: TRJQB4330
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiated
Packaging Details: Pallet or Wooden Case
Delivery Time: 30days
Payment Terms: T/T, Western Union, L/C
Supply Ability: 5000 Sets / Month
Detailed Product Description
Specification: 1050×1000×900mm Weight: 450kg
Motor: 18.5kw Type: Shear Pump
High Light:

drill fluid pump

,

cutter pump

Factory Price API Standard Oil Field Drilling Rig Equipment Shear Pump

Main Introduction

Shear pump is one of the important equipment in the drilling fluid circulation system, mainly used to deal with chemicals and soil, and quickly attain the purpose of configuring drilling fluid. Shear pump design has a special impeller structure, which can produce a strong shear force when the liquid flows. By smashing and dispersing chemical particles, soil and other solid phase in liquid flow, so that the liquid in the solid phase broken and evenly distributed.

TR Solids Control is a professional manufacturer engaged in shear pump with rich experience. Our shear pump can mix high property drilling mud very soon. Decrease the mixing time by much and enhance the drilling efficiency with great cost control, shear pump helps much on high quality drilling mud demand for well drilling.


Main Characterstics of Mud Shear Pump

  1. Material of mechanical seal is carbide alloy, its life is 5 times than normal.
  2. Oil seal adopts imported fluorine plastic seal, with good cooling capacity.
  3. Using special impeller and shear board, shear efficiency> 95%.
  4. Pump shell wall is thick, made by casting mold. Wear-resistant, fine appearance.
  5. Pump body adopts wear-resistant alloy cast iron with long service life.
  6. Bearings are internationally renowned brands SKF, quality assured.

Main Specifications of TR Shear Pump



Model Flow Rate Lift Motor Weight Dimension
TRJQB6545 150m3/h 45m 55kw 980kg 1050×1000×1360mm
TRJBQ6535 100m3/h 35m 37kw 800kg 1050×1000×1230mm
TRJBQ5430 60m3/h 30m 30kw 650kg 1050×1000×1100mm
TRJBQ4330 40m3/h 30m 18.5kw 450kg 1050×1000×900mm



18.5kw Motor Drilling Rig Equipment Shear Type Pump High Efficiency ISO 9001 0



TR Solids Control is a professional supplier of various oilfield equipment, including oil drilling and service equipment, oil production equipment, OCTG, wellhead & downhole tools and spare parts. Our products have already been exported to USA, South America, Africa, Middle East, Russia and some other countries (regions). TR Solids Control has become VIP (assigned) supplier and built strategic partnership with some countries' national petroleum companies.


Competitive Advantages

1. We offer high quality products at competitive price.
2. Shortest delivery time.
3. Flexible payment terms.
4. Timely after-sale service.
5. Most of our equipment can be replaceable with international brands.
6. Our products have been exported to Argentina, Egypt, US, Australia, Romania, Pakistan, Dubai, Abu Dhabi, Iran, India, Indonesia, Vietnam, Malaysia and many other countries.

Company Tenet

Customer's satisfaction is the highest pursuit of TR Solids Control.
