High Performance Mud Solids Control System For Oil And Gas Drilling Stainless Steel Material

High Performance Mud Solids Control System For Oil And Gas Drilling Stainless Steel Material
High Performance Mud Solids Control System For Oil And Gas Drilling Stainless Steel Material
video play

Large Image :  High Performance Mud Solids Control System For Oil And Gas Drilling Stainless Steel Material

Product Details:
Place of Origin: China
Brand Name: TR Solids Control
Certification: CE, ISO 9001:2000, ISO 9001:2008, API
Model Number: TR Solids Control
Payment & Shipping Terms:
Minimum Order Quantity: one set
Price: can be negotiated
Packaging Details: By container
Delivery Time: 30days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 15 sets per month
Detailed Product Description
Specification: 9000X2300X2300 Material: Stainless Steel
Operation Pressure: Atmospheric Pressure Type: Mud Tank
Port: Tianjin, China Application: Oil & Gas Drilling
High Light:

mud recycling system

,

mud treatment system

High Performance Mud Solid Control System for Oil and Gas Drilling



Brief Introduction



HDD mud recovery system is developed, designed and manufactured to meet trenchless technology requirements at home and abroad and is applied in purification treatment of mud returned from underground during horizontal directional drilling process. Cuttings with big particle sizes are separated by shale shaker, mud cleaner and other solids control equipment. Mud materials required are added and evenly mixed for circulation via mud mixer to meet performance requirements for reuse. Mud is pumped into horizontal directional drilling mud system by mud pump for recycling.


Function of Oil High Quality Drilling Mud Solids Control System

  1. With simple and compact structure, light weight, foldable or dismountable walkway and guardrail, being easy for transportation and installation.
  2. Mud recovery system is designed with benefits as reasonable structure, favorable treatment process and a wide range of application fields.
  3. Explosion-proof, rainproof and dustproof electric system to ensure construction safety and quality.
  4. Multifunctional and integrated design to meet mud purification, recycling, preparation and storage, greatly reducing overall dimensions of the tank system, meeting HDD requirements on site and space.

Technical Data of Drilling Mud Solids Control System for HDD



Model TRHDD-200 Model TRHDD-500 TRHDD-1000
Capacity 200GPM (50m3 /h) Capacity 500GPM (120m3 /h) 1000GPM (240m3 /h)
Shale Shaker TRZS752S Shale Shaker TRZS703/TRZS585 TRZS703/TRZS585
Upper Screen Area 0.875m2 Screen Area 2.7m2 2X2.7m2
Upper Screen Area 1.35m2 Mud Cleaner TRQJ250X1S-100X8N TRQJ250X2S-100X12N
Hydrocyclone 4"

Mud Cleaner

Mud Cleaner

10"×1pcs 10"×2pc
Hydroclycolone Qty 4 pcs Desilter Cyclone 4"×8pcs 4"×12pcs
Supply Pump Model TRSB4X3-12J Bottom Screen Area 1.35m2 2.12m2
Slurry Pump Model TRSB4X3-11J Supply Pump TRSB6X5-11J*2 TRSB8X6-11J*2
Mud Hopper TRSLH100 Slurry Pump TRSB6X5-12J TRSB8X6-12J
Gross Power 44kW Jet Mud Mixer TRSLH150-35(37KW) TRSLH150-35(45KW)
Total Volume 5m3 Mud Agitator TRJBQ7.5 TRJBQ7.5
Dimension 4000×2360×2940mm Gross Power 130kW 184kW
Weight 5500kg Total Volume 15m3 30m3
    Dimension 10000×2360×4228mm 12100×2630×4438mm
    Weight 17000kg 20000kg



Mud Solid Control System



Competitive Advantages


1. We offer high quality products at competitive price.
2. Shortest delivery time.
3. Flexible payment terms.
4. Timely after-sale service.
5. Most of our equipment can be replaceable with international brands.
6. Our products have been exported to Argentina, Egypt, US, Australia, Romania, Pakistan, Dubai, Abu Dhabi, Iran, India, Indonesia, Vietnam, Malaysia and many other countries.


Mud Solid Control System
Mud Solid Control System
